With the cloud remote access one or even more Hycleen AS systems and thus several buildings can be monitored. This turns the building manager into a digital service provider. You have remote access to your system.

In general, automation and digitization lower the cost of drinking water and energy consumption while also saving costs. The smart Hycleen valves with their different sensors facilitate the search for errors in the system. This considerably lowers the downtimes of drinking water systems. The data is recorded via the sensors in combination with the Controller.

You have the option of, on the one hand, using BACnet IP (Building Automation and Control networks) including the license for the release of the BACnet IP interface for connecting Hycleen AS to a building services management system. The interface allows linking the building services management (BSM) with reading rights. BACnet works with conventional BSM programs. The connection among the masters and the GLT+ mapping on the GLT level requires programming by a GLT specialist.

The following Hycleen Automation System data can be exported from the higher-level BMS by acquiring a license.

• Real time data monitoring
• Logging
• Alarm management

On the other hand, the connection can be created via Rest API (Representational State Transfer Application Programming Interface), including the license for the use of the REST API/JSON interface for connecting Hycleen AS to a building management system. Data communication is implemented via the respective interface. The interface allows linking the building services management (BSM) with reading rights. Rest API is the interface of the future. The connection among the masters and the GLT+ mapping on the GLT level requires programming by a GLT specialist.

The following Hycleen Automation System data can be exported from the higher-level BMS by acquiring a license.

• Real time data monitoring
• Logging
• Alarm management

License to activate the Master relay module. This license allows programming of the Master relay using the Actuator Automation application. This allows the implementation of further building and process automation functions. Immediately following the registration of the Hycleen Automation System, the module is available free of charge on the Georg Fischer CONNECT platform.

License to activate the Actuator Automation application module. This license allows programming of the Master and Uni Controller relay and the 4-20 mA input/output of the Uni controller. This allows the implementation of further building and process automation functions.

License for the release of the Hycleen Connect service – on a monthly basis. It allows connection of the Hycleen AS installation to the Hycleen Connect cloud for:

• Remote monitoring
• Automatic alarms
• Remote access
• Data management
• Asset manager

Drinking water installations are faced with a number of challenges in multi-family houses. On the one hand, not all apartments are always rented out, which means that their drinking water installations are not used.

Particularly when the rooms are occasionally empty, it is advisable to pay attention to hygiene in the drinking water installations and to flush these regularly. At the same time, people with various health conditions live in multi-family houses.

Therefore, the drinking water must have the required quality. The residents rely on clean and healthy drinking water coming our of their tabs. Building management companies usually are in charge of several buildings. It is therefore advantageous to them if they can centrally manage and control the drinking water supply.
