Copper valved manifolds with R20/R25 threaded ball and balancing valves

Copper valved manifolds with ProPEX ball valves are made of type L copper and feature ⁵⁄₈" and ³⁄₄" nominal branches that are 4" on center. The manifolds are available in 12-outlet configurations. The maximum recommended flow to the manifold based on manifold body diameter is 45 gpm. Note: ProPEX tool is required. ProPEX rings must be purchased separately.

This product is made to order, please contact customer service for lead time.

Download submittal

Find a distributor

Availability of specific products varies by distributor.

Item details

Name	Status			Detail
F2821220 2" x 4' Copper Valved Manifold with R20 Threaded Ball and Balancing Valves, 12 outlets	Phaseout	Download submittal		productFamilyDetail/tab/itemDetails/detailLink
F2821225 2" x 4' Copper Valved Manifold with R25 Threaded Ball and Balancing Valves, 12 outlets	Phaseout	Download submittal		productFamilyDetail/tab/itemDetails/detailLink
