Fluvia pump supply groups
Pre-assembled Uponor Fluvia pump supply groups
Designed to provide local water temperature control, Uponor Fluvia Pump Groups are complete preassembled and easy to install units. They can be used as part of the supply system which supports underfloor heating installations in residential and commercial buildings.
Fluvia pump group specifications
Application area:
- For control of underfloor heating systems in small zones up to 36 sqm (approximately)
- Max. 80° primary temperature
- Max. pressure: 6 bar
- Suitable for 9.9, 12 and 16mm pipe
Specification:
- Integrated pump: Q: 0,1 - 0,4 l/h, H: 0,2 - 1,1 m
- Valve kvs: 0.7m3/h
- Output: 1-3 kW
- Bracket for left or right installation
- Air bleed screw
- Secondary circuit temp. range 20-60°C
- Balancing valve
- Secondary loop 3/4" eurocone
- Primary valves with clamp connection for CU-Pipe 15mm
- Uponor Fluvia Push 12
- Uponor Fluvia MPG
- Uponor PPG 30
