PR4788040

Uponor PP-RCT Saddle, 8" x 4", for Outlet Fusion

Part no.PR4788040
Download submittal

Find a distributor

Availability of specific products varies by distributor.

Item details

Part information and details

Codes

CodesCMC|IMC|UMC

Dimensions

A [frac]1 47/64 inch
A [inch]1.732 inch
B [frac]33/64 inch
B [inch]0.512 inch
C [frac]4 59/64 inch
C [inch]4.929 inch
D [frac]4 13/32 inch
D [inch]4.407 inch
E [frac]6 3/64 inch
E [inch]6.043 inch
F [frac]7 57/64 inch
F [inch]7.898 inch
G [frac]3 1/64 inch
G [inch]3.022 inch
Equivalent length through [ft]5 ft
Weight per UOM [lbs/UOM]2.18 lbs/uom

Listings

ListingsICC-ES-PMG 1106|IAPMO-R&T 8358|QAI P321-5|IAPMO K-12775

Standards

StandardsASTM E84|NSF/ANSI 14|ASTM F2389|CSA B137.11

Technical Data

End Size 1 [inch|mm]8"
End Size 2 [inch|mm]4"
End Type 1Saddle
End Type 2Socket
Operating Pressure 1 [PSI]340 psi
Operating Pressure 2 [PSI]190 psi
Operating Pressure 3 [PSI]100 psi
Operating Temperature 1 [°F]73 °F
Operating Temperature 2 [°F]140 °F
Operating Temperature 3 [°F]180 °F
Material groupPP-RCT
