ProPEX LF Brass Transition Ball Valve (full port) SS Ball and Stem 2" PEX x 2" MNPT
Part no.LFT4912020SS
Find a distributor
Availability of specific products varies by distributor.
Item details
Part information and details
Codes
| Codes | UPC|IBC|IRC|IPC|NPC of Canada|UMC|IMC |
|---|
Dimensions
| A [frac] | 5 31/64 inch |
|---|---|
| A [inch] | 5.492 inch |
| B [frac] | 2 7/8 inch |
| B [inch] | 2.874 inch |
| C [frac] | 4 25/32 inch |
| C [inch] | 4.78 inch |
| D [frac] | 7 55/64 inch |
| D [inch] | 7.862 inch |
| E [frac] | 5 41/64 inch |
| E [inch] | 5.638 inch |
| F [frac] | 1 1/8 inch |
| F [inch] | 1.122 inch |
| G [frac] | 3 23/64 inch |
| G [inch] | 3.362 inch |
| H [frac] | 1 27/64 inch |
| H [inch] | 1.417 inch |
| I [frac] | 2 9/64 inch |
| I [inch] | 2.146 inch |
| J [frac] | 2 9/64 inch |
| J [inch] | 2.138 inch |
| Weight per UOM [lbs/UOM] | 3.04 lbs/uom |
Listings
| Listings | cNSFus-pw-G|U.P.Code |
|---|
Standards
| Standards | ASTM F877|NSF/ANSI/CAN 372|NSF/ANSI 359|ASTM F1960|CSA B137.5|NSF/ANSI/CAN 61|NSF/ANSI 14 |
|---|
Technical Data
| Cold working pressure (CWP) [psi] | 250 psi |
|---|---|
| Cv | 82.1 |
| End Size 1 [inch|mm] | 2" |
| End Size 2 [inch|mm] | 2" |
| End Type 1 | ProPEX |
| End Type 2 | MNPT |
| Operating Pressure 1 [PSI] | 200 psi |
| Operating Temperature 1 [°F] | 200 °F |
| Material group | LF Brass |
| Prop 65 label required? | Yes |
