ProPEX LF Brass Transition Ball Valve (full port) SS Ball and Stem 1" PEX x 1" MNPT
Part no.LFT4911010SS
Find a distributor
Availability of specific products varies by distributor.
Item details
Part information and details
Codes
| Codes | UPC|IBC|IRC|IPC|NPC of Canada|UMC|IMC |
|---|
Dimensions
| A [frac] | 3 37/64 inch |
|---|---|
| A [inch] | 3.579 inch |
| B [frac] | 1 17/32 inch |
| B [inch] | 1.535 inch |
| C [frac] | 2 63/64 inch |
| C [inch] | 2.984 inch |
| D [frac] | 6 17/64 inch |
| D [inch] | 6.26 inch |
| E [frac] | 4 35/64 inch |
| E [inch] | 4.547 inch |
| F [frac] | 11/16 inch |
| F [inch] | 0.685 inch |
| G [frac] | 2 15/64 inch |
| G [inch] | 2.236 inch |
| H [frac] | 3/4 inch |
| H [inch] | 0.748 inch |
| I [frac] | 1 3/16 inch |
| I [inch] | 1.181 inch |
| J [frac] | 1 11/32 inch |
| J [inch] | 1.339 inch |
| Weight per UOM [lbs/UOM] | 0.87 lbs/uom |
Listings
| Listings | cNSFus-pw-G|U.P.Code |
|---|
Standards
| Standards | NSF/ANSI/CAN 372|ASTM F877|NSF/ANSI 359|ASTM F1960|CSA B137.5|NSF/ANSI/CAN 61|NSF/ANSI 14 |
|---|
Technical Data
| Cold working pressure (CWP) [psi] | 250 psi |
|---|---|
| Cv | 17 |
| End Size 1 [inch|mm] | 1" |
| End Size 2 [inch|mm] | 1" |
| End Type 1 | ProPEX |
| End Type 2 | MNPT |
| Operating Pressure 1 [PSI] | 200 psi |
| Operating Temperature 1 [°F] | 200 °F |
| Material group | LF Brass |
| Prop 65 label required? | Yes |
