Minitec - retrofit underfloor heating

Minitec - low building floor heating with quick response time

Thanks to its minimal depth of around 1 cm, Uponor Minitec is the perfect system for renovation projects. The Uponor Minitec sheeting element, with the Uponor PE-Xa pipes measuring 9.9x1.1 mm, is easy to lay on existing screed, timber or tiles. The adhesive layer on the back of the sheet guarantees a secure bond during installation. The levelling layer is installed just above the studs, resulting in an increase in floor height of only 16 mm. Minitec is also possible to be installed with defined floor insulation materials. The special design of the sheeting elements ensures that the levelling compounds flow well and can bond directly with the substrate.

Application areas:

Radiant underfloor heating and cooling
Wet installation
Residential and commercial applications
For use with qualified filler materials

Specification:

Panel size: 1120 x 720 mm
Total panel height: 12 mm
Pipe dimensions: 9.9 x 1.1 mm
EN 13501-1 fire classification class E
Pipe spacing: 5, 10 or 15 mm
Net surface with overlapping nubs: 0.77 m²

Learn how to retrofit Uponor Minitec underfloor heating

Check out the video that explains the basic principle of how Uponor minitec underfloor heating is installed.

Benefits of the Uponor Minitec System

Underfloor heating for optimal use of renewable energy sources

Reduced bills – Save 62 kWh pear year by installing underfloor heating
High comfort standard – it is 60% quicker to warm up than standard UFH systems
Easily fits around obstacles – the Minitec system can easily fit around obstacles and there is no need to move door frames
3 days installation process – your system (including floor installation) will be fully completed in 3 days and ready to walk on after 34 hours
Uponor warranty – Uponor extended warranty by local regulations

Homeowner
Installer

Construction of Uponor underfloor heating system Minitec

Self adhesive fasteners on concrete floors

Heating loops mounted in Minitec self-adhesive nub foil. The fasteners are pre-glued and are fastened directly to the flat surface. Uponor Minitec Comfort pipe 9.9 x 1.1 mm are mounted with pipe distance in steps of 50 mm in the castellation of the panel. Thereafter everything is cast into filler, which in wet rooms is covered with a sealing layer.
