ReferenzenConcrete core activation ČSOB Prague,
Concrete core activation ČSOB Prague,
Prague,
Czech Republic
Concrete core activation ČSOB Prague
Heating and cooling using in the office building.
Location
Prague, Czech Republic
Fertigstellung
2019
Gebäudetyp
Bürogebäude
Product systems
Flächenheizung und -kühlung
Art des Projekts
Neubau
The project was executed using three basic components: PE-Xa 14x2.0 mm and PE-Xa 20x2.0 mm piping of a total length of approximately 350 km. The third components employed were Vario M distribution units.
- Instalace Praha
- ČSOB
The entire complex was planned using BIM technology
The new ČSOB bank headquarters for uses concrete core activation for heating and cooling. The entire building is equipped with a combination of the Contec and Contec ON systems. The Contec ON system is installed adjacent to the façade, while the Contec system is installed in the core of the building. The new headquarters building meets even the highest ecological standards in accordance with LEED Platinum international certification. The heating source are heat pumps with a total of 173 150 m-deep boreholes. The building complex comprises several “freestanding” buildings connected by a central atrium. The entire complex was planned and continues to be operated using BIM technology.
Concrete core activation ČSOB Prague
